8 - 2
Section F
Transmission
9803/6400
Section F
8 - 2
Issue 2*
Motor
Maintenance Specifications (continued)
Note 1. Lap, using very fine grade paste.
Part Name Appearance Standard Value Allowable Value Replaceable Part
(3) 1. Sliding area of the (21) Cylinder block kit
Shaft oil seal is deeply scarred
or rough surface is
observed.
2. Abnormally worn or broken 0.030 0.060
teeth of the engaged
teeth are observed.
(25) 1. All sliding areas are 0.15 0.4
Brake piston deeply scarred or rough
surface is observed.
(27) 1. The disk (wear-resistant Roughness 0.2a No seizure and Cylinder block kit
Disk plate material) is deeply scar deeper
scarred or has peeling. than 0.02mm
(12) 1. Flaking, peeling is observed See note 1. When scar
Ball bearing on the TENSOMEN. cannot be completely
removed, replace.
(13) 2. Pressure mark is observed
Ball bearing on the TENSOMEN.
3. Abnormal rotation Roughness 0.2a 0.8a No seizure Cylinder block kit
(abnormal sound, and scar deeper See note 1. When scar
roughness, etc.) than 0.02mm cannot be completely
is observed. removed, replace.
(11) 1. All sliding areas are
Piston deeply scarred or rough
surface is observed.
2.
Clearance with case is excessive.
0.020 0.040
3.
Shoe ball backlash is excessive.
0.5 1.0
(10) 1. Seizure is observed on Swash plate
Steel ball the contact area with the (9) Steel ball
swash plate.
*
*
*
*
*
To Next Page
