Section B Body & Framework

9803/6020

Section B

1 - 2

Issue 1

Weights

Weights (cont’d)

Part Name Weight

1 Travel motor 90 kg (198 lb)

2 Drive sprocket 22 kg (48 lb)

3 Idler wheel 37 kg (82 lb)

4 Top roller assembly 8 kg (18 lb)

5 Bottom roller assembly (Out) 46 kg (101 lb)

Bottom roller assembly (In) 30 kg (66 lb)

6 450 mm grouser shoe assembly 393 kg (867 lb)

7 600 mm grouser shoe assembly 582 kg (1283 lb)

8 Slew mechanism 176 kg (388 lb)

9 Slew ring bearing 100 kg (220 lb)

10 Counterweight 700 kg (1543 lb)

11 Engine 247 kg (545 lb)

12 Radiator 37 kg (82 lb)

13 Hydraulic pump 58 kg (128 lb)

14 Fuel tank 50 kg (110 lb)

15 Hydraulic tank 72 kg (159 lb)

16 Control valve 66 kg (146 lb)

17 Rotating coupling 26 kg (57 lb)

18 Boom 395 kg (871 lb)

19 Dipper 145 kg (320 lb)

20 Bucket 205 kg (452 lb)

21 Boom ram 84 kg (185 lb)

22 Dipper ram 76 kg (168 lb)

23 Bucket ram 50 kg (110 lb)

24 Dozer 240 kg (529 lb)

25 Dozer ram 20 kg (44 lb)

(Dry Weight)
