20
A
B
Inner Thigh Pad Fitting &
Adjustment
• To fit the inner thigh pads, Screws
A complete with Washers B should
be inserted through the carrier plate
and into the dedicated holes on the
underside of the Seating Unit.
• Tighten each screw using the 4mm
allen Key provided.
• Once held on (but not fully locked
off) you can continue to set the other
adjustment.
Abducting the legs
• With Screws A still loose, rotate the
inner thigh pad to the desired position.
• Once attained, lock off screws using
the 4mm Allen Key provided.
Flip Down the Inner Thigh Pad
(To facilitate Transfers)
• Press and Hold Button C, whilst
flipping down the inner thigh pad.
• To reengage the inner thigh pad,
simply rotate back up and into place
until it latches securely.
These pads enable you
to sit the client in an
abducted position which
can help to lower muscle
tone, create a wider sitting
base and maintain the
hips in a good position.
C
Thigh Pad Adjustment
