22 USER MANUAL
JDSU CLEANBLAST SYSTEM
The patented JDSU CleanBlast ber end face cleaning
systems provide a fast, eective, and cost-ecient
solution for removing dirt and debris from connectors
in most common applications. CleanBlast is a non-
contact system that uses a highly ltered stream
of pressurized gas with a vacuum circuit to create
a high ow rate jet across the surface of the ber.
A cleaning solvent is injected into the airow, and
the contamination from the end face along with
the solvent are then removed through the retrieval
circuit. The precise, highly ecient non-contact air-
solvent-air stream blasts and removes loose debris
with nearly 100-percent eectiveness.
CONTAMINATION MUST BE CLEANED from the end
face prior to mating in order to optimize the eciency
of an optical signal or interconnect.
CleanBlast eliminates the user sensitivity and
inconsistencies experienced with other cleaning tools
by removing loose debris at the push of a button. With
more than 8,000 cleaning cycles between rells, this
automated system cleans faster, more eectively, and
is less cost-per-clean than conventional methods.
• Faster, more eective, and less cost per clean
than using other methods
• Provides repeatable results
• Eliminates user sensitivity
• Removes (instead of spreading) loose debris
from ber optic end-faces
• Cleans both patch cords and bulkheads
• Multiple system congurations for a variety of
applications
• Clean multiple connector types by changing
the precision cleaning tips
CLEANBLAST SYSTEM OVERVIEW
