4 USER MANUAL
INTRODUCTION TO FIBER INSPECTION
Contamination is the number 1 reason for
troubleshooting optical networks. A single
particle mated into the core of a ber can cause
signicant back reection, insertion loss, and
equipment damage. Visual inspection is the only way
to determine if ber connectors are truly clean before
mating them.
The JDSU video ber inspection probe and handheld
display system is used to quickly and easily inspect
connector end faces, which ultimately minimizes
signal loss and optimizes test conditions. FBP-series
video probes are dual-magnication (200/400X),
high-performance handheld microscopes designed
for inspecting both female (bulkhead) and male (patch cord) connectors. The probe microscope can also be
combined with a USB converter module to inspect connectors via compatible test platforms and PC/laptop. This
versatile system oers a wide range of congurable solutions that can meet the demands of any application.
Our comprehensive selection of precision, stainless-steel ber inspection tips, adapters, and guides are carefully
engineered to produce consistent and accurate results. They are interchangeable and designed with a unique
optics architecture that enables the probe to interface with every connector and application in your network.
Implementing a simple yet important process of
proactively inspecting and cleaning before mating
can prevent poor signal performance and equipment
damage.
Proactively inspecting ber optic connectors will...
Reduce Aircraft On Ground (AOG) Instances
Reduce Troubleshooting
Optimize Signal Performance
Prevent Damage to Network Hardware
FIBER INSPECTION OVERVIEW
INSPECT BEFORE YOU CONNECT
BENEFITS OF PROACTIVE INSPECTION
