JDS Uniphase FBP Series - Clean: Common Methods; Clean Bulkhead; Clean Patch Cord

14 USER MANUAL
CLEAN
CLEAN: COMMON METHODS
REELSTYLE CLEANERS OR CLOTHS
REUSEABLE CLEANING STICK
When cleaning with the reel-style cleaners or cleaning cloths, push the latch lever to expose the cleaning area/
cloth and wipe the patch cord end along the cleaning cloth in the direction of the indicated arrow 2 to 3 times.
Note: Be sure to follow the recommended cleaning procedures dened in the Aircraft Maintenance Manual (AMM).
Reuseable cleaning sticks clean both the bulkhead
and patch cord sides.
SWAB
Use the swab to clean the bulkhead by inserting
into bulkhead, applying slight pressure, and twisting
the swab 2 to 3 times. Inspect again, and repeat if
necessary.
CLEAN BULKHEAD
CLEAN PATCH CORD
Note: For Cleanliness Acceptance Criteria, see the Aircraft Maintenance Manual (AMM)
for the Boeing 787.
Note: Be sure to follow the recommended cleaning procedures dened in the Aircraft Maintenance Manual (AMM).
