SPX532 – QUICKSTART GUIDE
13.2. MACHINE STABILITY SCREEN APPEREANCE
LMI config
page
Engine
page
Settings
page
Warning &
alarms page
ACTUAL LOAD CHART
OUTRIGGER 1 EXTENSION
Previous
page
OUTRIGGER 1 SWING ANGLE
OUTRIGGER 2 EXTENSION
OUTRIGGER 2 SWING ANGLE
OUTRIGGER 4 EXTENSION
OUTRIGGER 4 SWING ANGLE
OUTRIGGER 3 EXTENSION
OUTRIGGER 3 SWING ANGLE
CRANE TURRET ROTATION ANGLE
ROTATION ANGLE LIMITS OF
EACH WORKING ZONE
