SPX532 – QUICKSTART GUIDE
17. ALARMS & WARNINGS
If any alarm or warning is active, the code will be displayed on top of the screen.
When there are more alarms or warnings active, the codes will roll (see the picture below).
ALARMS & WARNING CODES:
Each alarm or warning code is composed by:
• ID: is the can bus unit/electronic device involved
(example: 1 = SPN06)
• FMI: is the family/group;
• SPN: a generic progressive number; each family (FMI)
has its own list which could restart from 1 or not.
IMPORTANT: Referring to alarm or warning codes, always indicate and
specify ID, FMI and SPN to identify it.
Push the Button 5 of the remote control (on top of the display) to open
the Warning page and Alarm page.
