16
SPX532 – QUICKSTART GUIDE
10. OUTRIGGERS UP & DOWN
Rotate the Working mode selector in position
and the Outriggers page will be displayed (see
picture beside).
IMPORTANT:
If the icons of the levers are not displayed on
bottom of the screen, the working mode needs to
be enabled!
10.1. ENABLE OUTRIGGERS FUNCTIONS
To enable the outriggers functions press once the Start button on the remote control.
The conditions to enable outriggers up & down functions are in the next page.
Once the functions are enabled, the Machine enabled icon (on top of the screen)
will become green and the icons of the levers will appear (on the bottom of the
screen).
MACHINE WORKING MODE ENABLED
MACHINE WORKING MODE NOT ENABLED
NO ICONS = WORKING MODE
NOT ENABLED
