Jensen AWM960 User Manual

AWM960
13
SYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
NTSC
PAL60
PAL
AUTO
DVD Operation (continued)
DVD Setup
Press SETUP on the remote control to access setup mode, which allows setup of the following four
DVD functions:
• System Setup
• Language Setup
• Audio Setup
• Video Setup
While in the setup menus, use your directional arrows to select and change settings. The “up” and
“down” arrows highlight the options, and the “right” and “left” arrows will change the setting for the
highlighted option.
System Setup
The system setup menu controls the following features:
TV System:
This item is used to select a TV signal system to match your TV set. Select one of the
following options: NTSC, PAL60, PAL or AUTO.
Video Format
.
TV Type: Select one of the following picture formats: 4:3PS, 4:3 LB or 16:9. 4:3 is a letterbox selection,
and 16:9 is wide screen.
Password:
This item allows the selection of a new four-digit code to use for security purposes.
Rating:
Select the parental control level for all DVD play. The security password is required to make
changes to this feature.
Default:
Use this item to restore default settings at any time.

Jensen AWM960 Specifications

Power

power supply requirements	DC 12 Volts, Negative Ground
operating voltage	11-16VDC
total system power	75 Watts Maximum

FM Tuner

tuning range	87.5-107.9FM
sensitivity	<2.5uV
stereo separation at 1 kHz	>30dB

AM Tuner

tuning range	530-1710
sensitivity	<15uV

Amplifier

output power	75 Watts Total (25 Watts per Channel)
output wiring	2/6 Speaker and Headphone System
output impedance	Compatible with 4-8 Ohm Speakers, 4 Ohm Load Minimum

DVD

frequency response	20-20, 000 Hz
channel separation	50dB
s/n ratio	70dB

Weight and Dimensions

overall dimensions	265mm(W)x178mm(H)x159mm(D)
mounting dimensions	235mm(W)x154mm(H)x133mm(D)
weight	3.75 lbs.(1.7 Kg)
