JHD905
8
JENSEN
HEAVY DUTY
JENSEN
MUTE
DISP
AM/FM
AUX
WB
TIMER
AM/FM/WB RECEIVER
JHD905
AUDIO
MENU
VOL+
VOL-
TUN TUN
+
1
234
5
6
SEEK
SEEK
+
A
U
X
I
N
AM
10
11a
11b
12a
12b
13
CH2
14
Tuner Operation
10. Select a Band
Press AM/FM (10) momentarily to directly access tuner mode from any other function mode. When the
unit is already in tuner mode, briefly press AM/FM to change between two AM bands (AM1 and AM2)
and three FM bands (FM1, FM2 and FM3).
NOTE: If the unit is programmed for European operation, the sequence will be MW1, MW2,
FM1, FM2 and FM3.
11. Manual Tuning
Press TUN- (11a) or TUN+ (11b) momentarily to tune the frequency one step higher or lower. Press
and hold TUN+ or TUN- for more than one second to tune continuously in the selected direction until
the button is released.
12. Seek Tuning
Press SEEK- (12a) or SEEK+ (12b) momentarily to automatically tune the frequency down or up to
the next strong station.
Radio and Weather Band Operation

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Jensen JHD905 and is the answer not in the manual?

Jensen JHD905 Specifications

Power IconPower
power supply requirementsDC 12 Volts, Negative Ground
current drain1.5 Ampere (max)
Audio IconAudio
loading impedance4 -8 ohms per channel
tone controls bass±10 dB at 100 Hz
tone controls treble±10 dB at 10 kHz
FM Tuner IconFM Tuner
tuning range87.5-108.0
fm mono sensitivity1.5uV
stereo separation @ 1 kHz>25dB
AM Tuner IconAM Tuner
tuning range522-1710
sensitivity<30uV
Weather Band IconWeather Band
sensitivity<1uV
Amplifier IconAmplifier
total system power15 Watts Maximum
signal to noise>70dB
Weight and Dimensions IconWeight and Dimensions
chassis dimensions131.6 (W) x 47.5 (D) x 86 (H)
