Section 4: Operation
5376000277 4-37
4. Rotate the “CAM” handles on
the hold back bars 180° to the
open position.
5. Swing the hold back bars out
toward the lower tow sling lugs
on the back of the body. Allow
the hold back bars to extend as
necessary.
6. Connect the hold back bars to
the tow sling lugs using the pins
that you removed earlier.
7. Rotate the “CAM” handles on
the hold back bars 180° to the
close position. Raise or lower
the boom slightly until the cam
locks on the tow sling hold bars
snap into the closed position.
