Section 4: Operation
5376000277 4-41
22. Install safety chains and towing
lights
23. After the tow is complete,
reverse the procedures to
unload the vehicle.
24. With the vehicle unloaded and
the tow sling extended, use the
underlift fold function to bring
the tow sling head back up into
its storage position.
25. Rotate the “CAM” handles on
the hold back bars 180° to the
open position.
26. Remove the pins from the hold
back bars at the rear of the body
The Bottom Anchor
Assembly (round tube) must
never be higher than the
attachment point on the rear
of the truck. The Stand Off
Bar Assembly acts as a pivot
in the event of a sudden
stop. This will assure that
the towed vehicle will not
catapult forward onto the
deck of the MPL40.
