4.0 Specifications
Model number ....................................................... JDP-20EVS-110 ............ JDP-20EVST-230.......... JDP-20EVST-460
Stock number ....................................................................... 354220 ............................. 354225........................... 354226
Motor and Electricals:
Motor type .......................................................... TEFC induction ................ TEFC induction.............. TEFC induction
Horsepower .......................................................... 2 HP (1.5kW) ................... 2 HP (1.5kW)................. 2 HP (1.5kW)
Phase ...................................................................................... 3 .......................................3..................................... 3
Voltage .............................................................................. 230 V ............................... 230 V............................. 460 V
Cycle .................................................................................. 60Hz ................................ 60Hz.............................. 60Hz
Listed FLA (full load amps) ...................................................... 6 .......................................6..................................... 3
Motor speed ........................................................................1720 ................................. 1720............................... 1720
Inverter ............................................ economic type, 115V, 1PH ....... M-type, 230V, 1/3PH......... M-type, 460V, 3PH
Power input requirements ................................... 115V, 1 phase ......... 230V, 1 or 3 phase............... 460V, 3 phase
Starting amps..................................................................... 9.2 A ..................................... ---................................... ---
Running amps (no load) .................................................... 1.7 A ..................................... ---................................... ---
Power cable ....................................................... 3x14AWG, 6 ft. .................... 14AWG, 6 ft................... 14AWG, 6 ft.
Power plug ......................................................................... 120V ..................... not provided................... not provided
Recommended circuit and fuse/breaker size
1
........................15 ..................................... 15................................... 15
Sound emission without load
2
.......................................... 70 dB ............................... 70 dB............................. 70 dB
Coolant pump ................................................. 1/8HP 115V 1PH ............. 1/8HP 230V 1PH............ 1/8HP 460V 3PH
Capacities:
Drilling capacity, cast iron .............................................. 1-1/2 in. ............................ 1-1/2 in........................... 1-1/2 in.
Drilling capacity, mild steel ............................................ 1-3/8 in. ............................ 1-3/8 in........................... 1-3/8 in.
Tapping capacity, cast iron ....................................................n/a ............................... 7/8 in.............................. 7/8 in.
Tapping capacity, mild steel ..................................................n/a ............................... 3/4 in.............................. 3/4 in.
Spindle to table maximum distance ............................. 30-1/4 in. .......................... 30-1/4 in......................... 30-1/4 in.
Spindle to base maximum distance ............................. 44-1/2 in. .......................... 44-1/2 in......................... 44-1/2 in.
Spindle to column maximum distance ....... 10-7/16 in. (265mm) ........ 10-7/16 in. (265mm)....... 10-7/16 in. (265mm)
Coolant capacity ........................................................ 2 gal. (9L) ........................ 2 gal. (9L)....................... 2 gal. (9L)
Spindle:
Spindle taper ...................................................................... MT-3 ................................ MT-3.............................. MT-3
Spindle speed ................................................................ variable ............................ variable.......................... variable
Spindle speed range ....................................... 65-540/245-2000 ............. 65-540/245-2000............ 65-540/245-2000
Spindle travel ................................................... 6 in. (152.4 mm) ...............6 in. (152.4 mm)............. 6 in. (152.4 mm)
Gear reduction ................................................................ 48/35T ............................. 48/35T............................ 48/35T
Rotation .......................................................................... fwd/rev ............................. fwd/rev........................... fwd/rev
Table and Column:
Table size ................................................................................... 22 x 18-3/4 in. (559 x 476 mm) ...............................
Table working surface ................................................................ 18-1/8 x 14-3/4 in. (460 x 375 mm) .........................
Table travel
Without rack adjustment ............................... 15 in. (381mm) .................15 in. (381mm)............... 15 in. (381mm)
Maximum travel with rack adjustment ........... 20 in. (508mm) .................20 in. (508mm)............... 20 in. (508mm)
T-slot number ........................................................................... 3 .......................................3..................................... 3
T-slot size ............................................................ 5/8 in. (16mm) ................. 5/8 in. (16mm)................ 5/8 in. (16mm)
T-slot centers ............................................... 7-7/16 in. (189mm) .......... 7-7/16 in. (189mm)......... 7-7/16 in. (189mm)
Table weight capacity ........................................... 154 lb. (70kg) ................... 154 lb. (70kg)................. 154 lb. (70kg)
Column diameter ........................................... 4-1/2 in. (114mm) ............ 4-1/2 in. (114mm)........... 4-1/2 in. (114mm)
Base:
Base size.................................................................................... 27 x 19 in. (686 x 483mm) ......................................
Base working surface…………………………………………….14-3/4 x 11-13/16 in. (375 x 300mm) ..........................
T-slot number ........................................................................... 2 .......................................2..................................... 2
T-slot size ............................................................ 5/8 in. (16mm) ................. 5/8 in. (16mm)................ 5/8 in. (16mm)
Main materials:
Head .......................................................... cast iron, steel cover ........ cast iron, steel cover...... cast iron, steel cover
Table and Base ............................................................. cast iron ........................... cast iron......................... cast iron
Spindle and Quill ................................................................. steel ................................. steel............................... steel
Column ............................................................................... steel ................................. steel............................... steel
