6
4.0 Specifications for JDP-20VS series Drill Press
Model number
JDP-20VS-1 JDP-20VS-3 JDP-20VST
Stock number 354230 354231 354240
Motor and Electricals
Motor type TEFC induction
Horsepower 2 HP (1.5kW)
Phase 1 3 3
Voltage 115/230 V
(prewired 115V)
230/460 V
(prewired 230V)
230 V only
Cycle 60 Hz
Listed FLA (full load amps) 25/13 7/3.5 7/6.6
Motor speed 1720 RPM 1720/850 RPM
Power cable SJT 12AWG, 6 ft. AWM 14AWG, 4 ft. SJT 14AWG, 6 ft.
Main Power plug Not provided
Work light 6W, 12V DC, input 110V AC
Work light power cable SVT 18AWG, 6 ft. with 110V plug SVT 18AWG (to box)
Power transfer Belts
Gear ratio (center pulley) 27T / 62T (spindle)
Recommended overcurrent protection
1
30A (115V)
15A (230V)
15A 15A
Capacities
Drills to center of circle 20 in. (508 mm)
Drilling capacity, cast iron 1-1/4 in. (31.8 mm)
Drilling capacity, mild steel 1 in. (25.4 mm) 1-3/8 in. (35 mm)
Tapping capacity, cast iron n/a 3/4 in. (19 mm)
Tapping capacity, mild steel n/a 5/8 in. (15.9 mm)
Spindle to table distance, maximum 30-1/4 in. (768.4 mm)
Spindle to base distance 43-1/2 in. (1105 mm)
Spindle to column distance 10-7/16 in. (265 mm)
Coolant capacity (optional) 2 gal. (7.6 L)
Spindle
Spindle taper MT-3
Number of spindle speeds Variable
Spindle speed range 300 – 2,000 RPM 150 – 2,000 RPM
Spindle travel 6 in. (152.4 mm)
Rotation Fwd/rev
Table and Column
Table size LxW 22 x 18-3/4 in. (559 x 476.3 mm)
Table working surface 18-1/8 x 14-3/4 in. (460.4 x 375 mm)
Table effective travel (w/o rack adjustment) 15 in. (381 mm)
Table max. travel (with rack adjustment) 20 in. (508 mm)
Number of T-slots 3
T-slot size 5/8 in. (16 mm)
T-slot centers 3-3/4 in. (95 mm)
Table weight capacity 154 lbs. (70 kg)
Column diameter 4-1/2 in. (114.3 mm)
Base
Base size 27 x 19 in. (686 x 482.6 mm)
Base working surface 15 x 12 in.(380 x 304mm)
Number of T-slots 2
T-slot size 5/8 in. (16 mm)
