13
Lint Drawer/Lint Drawer Switch Assembly
For Models Mfd. prior to July 1, 2002
Illus. No. Part No. Qty. Description
1 883140 1 White Lint Drawer Assembly
(includes illus. nos. 1 and 2)
2 117605 5 Gasket (sold by the foot)
3 122116 1 Lint Drawer Switch
4 122605 1 4-Pin Socket Connector ONLY
5 122701 4 Socket Terminal ONLY
122801 1 Pin/Socket Extraction Tool
6 833123 1 Lint Drawer Switch Box Assembly
(includes illus. nos. 3 through 6)
304136 1 Lint Drawer Switch Box Cover ONLY
7 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
8 122700 4 Pin Terminal ONLY
9 122604 1 4-Pin Connector ONLY
To Next Page
