4
Phase 7 OPL Microprocessor Control Panel Assembly
Illus. No. Part No. Qty. Description
1 112571 1 Phase 7 OPL Keyboard
2 850984 1 Phase 7 Microprocessor Controller (computer) Panel ONLY
883301 1 Phase 7 OPL Reversing Microprocessor Controller (computer) Control
Panel Assembly Complete
(includes illus. nos. 1 through 7)
3 883277 1 Phase 7 OPL Microprocessor Controller (computer) ONLY
4 150005 2 #6-32 x 3/4” Phillips Round Head Machine Screw
5 153010 2 #6 Star Washer
6 136016 1 5-Amp Fuse
7 136097 1 500 mA Fuse
