JLA Phase 7 D30 - Steam Coil;Air-Operated Steam Damper Assembly

33
Illus. No. Part No. Qty. Description
1 165013 1 Steam Coil Assembly
2 153002 6 5/16” Lock Washer
3 152004 6 5/16-18 Hex Nut
4 152002 4 1/4-20 Hex Nut
5 153007 4 1/4” Lock Washer
6 820321 2 Steam Damper Hinge Assembly
7 880835 1 Steam Damper Assembly
(includes illus. nos. 7, 10, and 11)
8 153007 4 1/4” Lock Washer
9 152002 4 1/4-20 Hex Nut
10 115995 48 Steam Damper Gasket (sold by the inch)
11 102350 1 Steam Damper Foam (68-1/2” length)
12 151006 1 5/16-24 Stainless Steel Acorn Nut
13 152051 1 5/16-24 Right Hand Jam Nut
14 100495 1 11/16” Dia. x 3” Stroke Piston
15 323365 2 Left and Right Piston Support
16 152002 2 1/4-20 Hex Nut
17 153007 2 1/4” Lock Washer
18 100472 1 1/4” Poly x 1/8” M.P.T. Connector
19 143110 1 1/4” Poly-Flo Tubing
20 100472 1 1/4” Poly x 1/8” M.P.T. Connector
21 100496 1 1/8” Needle Valve
22 143238 1 1/8” Brass Close Nipple
23 100498 1 3-Way Micro Valve - 24 VAC
24 150002 2 #6-32 x 1” Phillips Round Head Machine Screw
25 153010 2 #6 Star Washer
26 152000 2 #6-32 Hex Nut
27 330987 1 Micro Valve Support
28 152002 2 1/4-20 Hex Nut
29 153007 2 1/4” Lock Washer
30 100520 1 1/8” N.P.T. Silencer (muffler)
Steam Coil/Air-Operated Steam Damper Assembly
