JLA Phase 7 D30 - Motor Mount Assembly

17
Illus. No. Part No. Qty. Description
1 100103 1 4L-510 V-Belt (motor to idler)
2 100705 1 3/16” x 3/16” x 1-3/8” Key
3 101131 1 1/2” x 2-1/4” Motor Pulley
(for models mfd. as of August 22, 2002)
101133 1 5/8” x 2-1/4” Motor Pulley
(for models mfd. prior to August 22, 2002)
4 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
5 153002 4 5/16” Lock Washer
6 153001 4 5/16” Flat Washer
7 181049 1 1/2 HP 240v 1ø 50 Hz Plug-Type Motor
(for models mfd. as of August 22, 2002)
100066 1 1/2 HP 240v 1ø 50 Hz Totally Enclosed, Fan-Cooled (T.E.F.C.) Plug-Type
Motor
(for models mfd. prior to August 22, 2002)
8 122701 8 Socket Terminal ONLY
122801 1 Pin/Socket Extraction Tool
9 137030 1 8-Pin Housing Connector
10 152004 4 5/16-18 Hex Nut
11 153002 4 5/16” Lock Washer
12 153001 4 5/16” Flat Washer
13 117604 4 Neoprene Sponge Tape (sold by the foot)
14 154000 4 5/16-18 Tinnerman Nut
15 850017 1 1/2 HP Motor Mount ONLY (56Z frame)
817076 1 1/2 HP 240v 1ø 50 Hz Motor Mount Assembly Complete with Plug Motor
(includes illus. nos. 2 through 7 and 13 through 20)
16 153050 2 1/2” S.A.E. Flat Washer
17 100604 1 12-1/2” Impellor with 1/2” Bore
18 100702 1 1/8” x 1/8” x 1-1/2” Key
19 153050 2 1/2” S.A.E. Flat Washer
20 152006 2 1/2-20 Left Hand Jam Nut
Motor Mount Assembly
