31
S.A.F.E. Solenoid and Piping Assembly
Illus. No. Part No. Qty. Description
1 165114 1 S.A.F.E. Solenoid Valve 24V 50/60 Hz
2 143220 1 3/8” F.P.T. Brass Tee
3 143251 1 3/8” M.P.T. Brass Plug
4 143208 2 3/8” Comp x 3/8” M.P.T. Brass Connector
5 143099* 6' 3/8” OD x 0.035 Wall Copper Tubing
6 311588 1 Sprinkler Head Mounting Plate
7 143303 1 3/8” N.P.T. Brass Locknut
8 143155 1 3/8” Brass Elbow 90°
9 150430 2 #10 x 1/2” Self Drilling Screw
10 150301 2 #8-18 x 7/16” TEK Screw
11 143581 1 3 GPM 3/8” F.P.T. Spray Nozzle
12 142887 1 3/4” to 3/8” Bushing for FSS Valve
13 824081 1 R.C. Network Assembly
* Sold by the foot.
