2
OPL Control Door Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty. Description
1 883574 1 White OPL Control Door
(includes illus. nos. 1 and 3)
2 150321 2 #10-32 x 1/2” Phillips Machine Screw
3 117604 4 Neoprene Sponge Tape (sold by the foot)
4 150317 2 #10-16 x 3/4” TORX + BTN Type 1
5 102502 1 Control Door Support Rod
6 154011 2 #10-32 Multi-Thread U-Nut
7 102603 1 Control Door Rod Support Catch
8 102601 1 Control Door Retainer Clip
