Sensor Bracket Assemblies
For Models Mfd. prior to July 1, 2002
Illus. No. Part No. Qty. Description
1 882533 1 1/4” Temperature Sensor Probe Assembly
(includes illus. nos. 1 and 5 through 7)
2 130301 1 225º Manual Reset Thermostat
3 153010 2 #6 Star Washer
4 152000 2 #6-32 Hex Nut
5 121028 2 Insulated Terminal ONLY
6 122701 4 Socket Terminal ONLY
7 122605 1 4-Pin Socket Connector ONLY
8 154007 2 1/4” Tinnerman Push On Fastener
9 150005 2 #6-32 x 1/4” Round Head Machine Screw
10 818086 1 Microprocessor Sensor Bracket Assemblies Complete
(includes illus. nos. 1 through 10)
322080 1 Universal Sensor Bracket ONLY
11 122604 1 4-Pin Connector ONLY
12 122700 4 Pin Terminal ONLY
13 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
14 150005 5 #6-32 x 1/4” Slotted Round Head Machine Screw
15 130111 1 130º Thermostat
16 130100 1 150º Thermostat
17 130301 1 225º Manual Reset Thermostat
18 130101 1 180º Thermostat
19 153010 5 #6 Star Washer
20 152000 5 #6-32 Hex Nut
21 882535 1 Sensor Jumper
22 121028 4 Insulated Terminal ONLY
23 122701 4 Socket Terminal ONLY
122801 1 Pin/Socket Extraction Tool
24 122605 1 4-Pin Socket Connector ONLY
882534 1 Sensor Bracket Harness Assembly
(includes illus. nos. 22 through 24)
25 818083 1 Noncomputer Sensor Bracket Assembly Complete - Includes Thermostats
(includes illus. nos. 14 through 25)
322080 1 Universal Sensor Bracket ONLY
26 122604 1 4-Pin Connector ONLY
27 122700 4 Pin Terminal ONLY
28 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
