Electric Oven Assembly
Illus. No. Part No. Qty. Description
1 803003* 1 Small Electric Oven Box ONLY
---------* 1 Electric Oven Assembly Complete
2 ---------* - Electric Element
3 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
4 802800 1 Sail Switch Box with Bracket and Cover ONLY
802801 1 Sail Switch Box Assembly Complete
(includes illus. nos. 4 through 12)
5 154004 1 Twin Speed Nut
6 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
7 802799 1 Sail Switch Box Cover ONLY
8 122200 1 Sail Switch ONLY
9 150303 2 #4 x 3/4” Pan Head “A” Machine Screw
10 105500 1 Sail Switch Actuator Rod
11 319202 1 Sail Switch Damper (flat)
12 154002 1 1/8” Push On Fastener
13 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
14 803100 1 Electric Oven Front Cover ONLY
15 320611 1 Large Relay Box Cover ONLY
16 150301 3 #8-18 x 7/16” Phillips Pan Head TEK Screw
17 130400 1 290º Hi-Limit Thermostat
18 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
19 154001 1 #10-24 Speed Nut
20 121010 1 L-70 Ground Lug
21 152014 3 1/4-20 Free Spin Wash Nut
22 --------* 1 Oven Relay
23 --------* 1 Oven Relay Replacement Coil
24 120081 - Internal Ceramic Insulator (2 per element)
25 120080 - External Ceramic Insulator (2 per element)
26 152008 - #10-32 Hex Nut (4 per element)
27 121011* - Bus Bar
28 --------* - Oven Wire with Crimp Lug
29 153009 - #10 Star Washer (2 per element)
30 321300 1 Small Electric Oven Right Side Cover ONLY
31 150207 1 #10-24 x 1/2” Phillips Head Machine Screw
882604** 1 Steam to Electric Interface Assembly
* Refer to Electrical Oven Component Application Chart on
page 35.
** Needed when converting steam heat to electric heat.
