Section 7 - Lubrication and Maintenance
7-731200345
E. Wheel Installation
Torque lug nuts after first 50 hours and after each wheel installation.
Note: If machine is equipped with directional tire assemblies, the wheel and tire assemblies
must be installed with the directional tread pattern “arrows” facing in the direction of forward
travel.
1. Start all nuts by hand to prevent cross threading. DO NOT use a lubricant on threads
or nuts.
2. Tighten lug nuts in an alternating pattern as indicated in figure. Refer to the
Operation & Safety Manual supplied with telehandler for torque values.
WARNING
TIP OVER HAZARD. Lug nuts must be installed and maintained at the proper torque
to prevent loose wheels, broken studs and possible separation of wheel from the axle.
