JLG 600A - Major Component Weights

SECTION 1 - SPECIFICATIONS
1-6 – JLG Lift – 3121201
1.9 MAJOR COMPONENT WEIGHTS
Table 1-21. Cylinder Specifications - 600AJ
DESRIPTON BORE STROKE ROD DIA.
Lower Lift 6.5
(165.1)
34.0625
(865.2)
2.5
(63.5)
Tower Tele-
scope
3
(76.2)
63.75
(1619.3)
2
(50.8)
Upright Level 6
(152.4)
34.625
(879.5)
3
(76.2)
Upper Lift 4
(101.6)
36.625
(930.3)
2.5
(63.5)
Upper Tele-
scope
3
(76.2)
134.375
(3413.1)
2
(50.8)
Steer (2WD/
2WSl
2.5
(63.5)
8.812
(204.7)
1.25
(31.8)
Steer (4WD/
2WS)
2.5
(63.5)
10.75
(273.1)
1.25
(31.8)
Lockout (2WD) 3.5
(88.9)
3.875
(98.4)
2.5
(63.5)
Lockout (4WD 3.5
(88.9)
3.875
(98.4)
2.5
(63.5)
Master 3.5
(88.9)
13.0625
(331.8)
1.5
(38.1)
Slave 3.5
(88.9)
13.0625
(331.8)
1.5
(38.1)
Lift (Articulat-
ing Jib Boom)
3
(76.2)
25.5
(647.7)
1.5
(38.1)
Table 1-22. Major Component Weights - 600A
LB. KG.
Platform Control Console 250 113
Platform Level Cylinder 46 21
Main Boom (
Includes Lift Cyl., Rotator, and Support) 1832 831
Upright including Master Cylinder 547 248
Upright Level Cylinder 316 143
Tower Boom Complete 1218 553
Turntable Complete (including engine) 9240 4191
Chassis Complete (w/pneumatic tires) 6834 3100
Chassis Complete (w/foam-filled tires) 7918 3592
Pneumatic Tire & Wheel Assembly 235 107
Foam-filled Tire & Wheel Assembly 440 200
Segmented Tire & Wheel Assembly 320 145.5
Machine Complete (GVW) - 2WD
w/pneumatic tires 20700 9390
Machine Complete (GVW) - 4WD
w/pneumatic tires 21150 9594
Table 1-23. Major Component Weights - 600AJ
LB. KG.
Platform Control Console 250 113
Platform Level Cylinder 60 27
Main Boom (
Includes Lift Cyl., Rotator, and Support) 1685 764
Upright including Master Cylinder 547 248
Upright Level Cylinder 316 143
Tower Boom Complete 1218 553
Turntable Complete (including engine) 9740 4418
Chassis Complete (w/pneumatic tires) 6834 3100
Chassis Complete (w/foam-filled tires) 7918 3592
Pneumatic Tire & Wheel Assembly 235 107
Foam-filled Tire & Wheel Assembly 440 200
Segmented Tire & Wheel Assembly 320 145.5
Machine Complete (GVW) - 2WD
w/pneumatic tires 22100 10025
Machine Complete (GVW) - 4WD
w/pneumatic tires 22295 10113
