SECTION 6 - JLG CONTROL SYSTEM
6-56 – JLG Lift – 3121201
6.9 ANALYZER DIAGNOSTICS MENU
STRUCTURE
In the following structure descriptions, an intended item is
selected by pressing ENTER; pressing ESC steps back to
the next outer level. The LEFT/RIGHT arrow keys move
between items in the same level. The UP/DOWN arrow
keys alter a value if allowed
Table 6-7. Adjustments - Personality Descriptions
DRIVE
ACCEL … Displays/adjusts drive acceleration
DECEL … Displays/adjusts drive deceleration
MIN FORWARD … Displays/adjusts minimum forward drive speed
MAX FORWARD … Displays/adjusts maximum forward drive speed
MIN REVERSE … Displays/adjusts minimum reverse drive speed
MAX REVERSE … Displays/adjusts maximum reverse drive speed
ELEVATED MAX … Displays/adjusts maximum drive speed
NOTE: used when elevation cutout switches are limiting maximum speed
CREEP MAX … Displays/adjusts maximum drive speed
NOTE: used when creep switch on pump pot is active
STEER MAX … Displays/adjusts the maximum steer speed
LIFT
ACCEL … Displays/adjusts upper lift acceleration
DECEL … Displays/adjusts upper lift deceleration
MIN UP … Displays/adjusts minimum upper lift up speed
MAX UP … Displays/adjusts maximum upper lift up speed
CREEP UP … Displays/adjusts maximum upper lift up speed
NOTE: used when creep switch on pump pot is active
MIN DOWN … Displays/adjusts minimum upper lift down speed
MAX DOWN … Displays/adjusts maximum upper lift down speed
CREEP DOWN … Displays/adjusts maximum upper lift down speed
NOTE: used when creep switch on pump pot is active
