SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
7-4 3121716
Dimensional Data
Table 7-4. Dimensional Data
Machine Length (stowed)
E 400A n
E/M400AJP; E/M400AJPn
18 ft. 1 in. (5.50 m)
22.0 ft. (6.7 m)
Machine Height (stowed)
E/M400AJP
E400An; E/M400AJPn
6 ft. 7 in. (2.0 m)
6 ft. 5.75 in. (1.31m)
Up and Over Platform Height 21 ft. 5 in. (6.55 m)
Horizontal Reach @ Maximum Up and
Over
E 400A n
E/M400AJP, E/M400AJPn
21 ft. 2 in. (6.41 m)
22 ft.-5 in. (6.83 m)
Machine Width
E/M400AJP
E400An; E/M400AJPn
5 ft. 9 in. (1.75 m)
4 ft. 11 in. (1.50 m)
Wheel Base 6 ft. 7.0 in. (2.00 m)
Working Height 46 ft. 0 in. (14.02 m)
Platform Height 40 ft. 0 in. (12.19 m)
Track Width
E/M400AJP
E400An; E/M400AJPn
5 ft. 0 in. (1.51 m)
4 ft. 3.75 in.(1.31 m)
Tail Swing (Any Position)
E/M400AJP, E/M400AJPnarrow
E400Anarrow
0
4 in. (10 cm)
Ground Clearance
E/M400AJP
E 400An, E/M400AJPn
8.5 in. (0.22 m)
5 in. (0.13 m)
Table 7-4. Dimensional Data
