JLG E400A Narrow - Skyguard - Skyeye; Skyguard Function Table

SECTION 4 - MACHINE OPERATION
3121716 4-15
Reattach magnetic end of cable to bracket if it becomes discon-
nected.
SkyGuard - SkyEye
Operator passes through path of sensor beam.
SkyGuard Function Table
0"$
0"$
Drive
Forward
Drive
Reverse
Steer Swing
Tower
Lift Up
Tower
Lift
Down
Boom
Lift Up
Boom
Lift
Down
Boom
Tele Out
Boom
Tele In
Jib Lift
Jib
Swing
Basket
Level
Basket
Rotate
R * / C ** R C R R C R C R C C C C C
R = Indicates Reversal is Activated
C = Indicates Cutout is Activated
* DOS (Drive Orientation System) Enabled
* * DOS Not Enabled, machine is driving straight without steering, and any other hydraulic function is active
