SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION
2-4 3121716
























0"$
Figure 2-1. Basic Nomenclature
1. Pl atfo rm Cont rol Con sole
2. Pl atfo rm
3. U ppe r Bo om
4. Tel esco pe Cy li nder (in side )
5. Ma ster Cy lin der
6. U ppe r Upr ight
7. U ppe r Lif t Cy li nder
8. Mi d Li ft Cyli nde r
9. Lower Boo m
10. Turntable
11. Frame
12. Steer Wheels
13. Drive Wheels
14. Battery Box
15. Lower Lift Cylinder
16. Lower Link
17. Lower Upright
18. Upper Link
19. Mid Boom
20. Slave Cylinder
21. Footswitch
22. SkyGuard (If Equipped)
23. Cross Rail (If Equipped)
