SECTION 3 - MACHINE CONTROLS AND INDICATORS
3-12 3121716
Table 3-1. Simultaneous Functions
If This Function is Selected: These Functions Will Also Work at the Same Time:
Drive and Steer Swing Lower Lift** Upper Lift** Telescope
Swing
Drive and Steer
Lower Lift** Upper Lift** Telescope
Lower Lift
Drive and Steer
Swing* No Telescope*
Upper Lift
Drive and Steer
Swing No Tel escope
Te le sco pe
Drive and Steer
Swing* Lower Lift** Upper Lift**
Jib
Drive and Steer
Swing* Lower Lift** Upper Lift** Telescope
Platform Rotate
Drive and Steer
No No No No
Note: Boom functions may be slower when selected with another function than when operated individually, due to sharing of oil.
* These functions may move very slowly (or not at all) if the first function selected (Lower Lift or Swing) is being operated at full speed, due to sharing of oil.
** Lower Lift and Upper Lift will not function simultaneously. Upper Lift always prevails.
