JLG E400A Narrow - Page 64

SECTION 4 - MACHINE OPERATION
4-4 3121716
Figure 4-2. Position of Least Backward Stability
LOWER BOOM
FULLY ELEVATED
MID BOOM
FULLY ELEVATED
UPPER BOOM
FULLY ELEVATED
AND RETRACTED
PLATFORM
ROTATED
90 DEGREES
MACHINE WILL "TIP OVER" IN THIS
DIRECTION IF OPERATED ON AN
OUT-OF-LEVEL SURFACE
