JLL S400 - Electrical Power and Assembly Steps

8
See content listing and diagram below for carton
contents. See Customer Service for contact
information if any parts are missing.
Electrical Power Requirements
220VAC 50Hz
Content listing
ITEM QUANTITY DESCRIPTION
1 1 Manual book
2 1 Powerd cord
3 1 Auxiliary cable
4 1 Installation tools
5 1 Fuse
6 2 Vertical frames
7 1 Safety key
8 2 Frame cover
9 1 Lubrication oil
10 1 Support crossbar
11 1 Console
12 1 Running deck
Installation tools
QUANTITY DESCRIPTION
2
Black arc washer
(M8)
2
Black at washer
(M8)
2
+ 2 spares
Silver split lock
washer (M8)
6
Silver at washer
(M8)
2
Split lock washer
(M10)
2 Flat washer (M10)
2
Tapping screw (ST 4
x 20)
12
Black Allen head bolts
(M8 x 15)
2
Black Allen head bolts
(M10 x 50)
1 Screwdriver
1 Allen key (M6)
• At least two people must lift,
move or assemble it.
• Use safe lifting methods.
Warning: Heavy equipment.
www.jlltness.co.uk www.jllelectronics.co.uk
1
3
5
4
6
7
9
11
12
1. Before starting the machine,
place your feet on the side
frames located on each side
of the running belt. NOTE: DO
NOT stand on running belt.
2. After the belt starts moving,
you can start walking on the
running belt and enjoy the run!
Warning: Falling hazard.
When starting unit.
