Johnson Controls 100 Series Engineering Guide

59
JOHNSON CONTROLS
FORM 100.50-EG12 (918)
TABLE 28 - SUPPLY, RETURN, AND EXHAUST FAN MOTOR DATA
PREMIUM EFFICIENCY - ODP PREMIUM EFFICIENCY - TEFC
MOTOR
HP
NOMINAL VOLTAGE
MOTOR
HP
NOMINAL VOLTAGE
208/3/60 230/3/60 460/3/60 575/3/60 208/3/60 230/3/60 460/3/60 575/3/60
FLA FLA FLA FLA FLA FLA FLA FLA
5 14 13.2 6.6 5.3 5 13.9 13.4 6.7 5.3
7.5 20.4 19.4 9.7 8 7.5 20 19 9.5 7.6
10 26 25 12.5 10 10 25.4 24 12 9.6
15 38 36 18 14.2 15 38 36.2 18.1 14.6
20 52 48 24 18.9 20 52 48 24 19.2
25 64 60 30 24.5 25 64 62 31 24
30 76 72 36 28 30 78 76 38 29
40 99 98 49 40 40 102 96 48 37
50 121 114 57 46 50 128 116 58 45
60 144 136 68 56 60 149 135 67.8 54.4
TABLE 29 - POWER SUPPLY VOLTAGE LIMITS
Nominal Voltage Power Supply Minimum Voltage Maximum Voltage
208 200V/3Ph/60Hz 187 218
240 230V/3Ph/60Hz 216 252
480 460V/3Ph/60Hz 432 504
600 575V/3Ph/60Hz 540 630
TABLE 30 - CONDENSER FAN MOTOR RLA
RLA EACH MOTOR
208V/3PH/60HZ 230V/3PH/60HZ 460V/3PH/60HZ 575V/3PH/60HZ
7.3 6.2 3.1 2.5
MODEL QUANTITY OF FANS 208V/3PH/60HZ 230V/3PH/60HZ 460V/3PH/60HZ 575V/3PH/60HZ
YPAL070–105 6 43.8 37.2 18.6 15.0
TABLE 31 - MISCELLANEOUS ELECTRICAL DATA
DESCRIPTION
NOMINAL VOLTAGE
208V 230V 460V 575V 380V-60
AMPS AMPS AMPS AMPS AMPS
Control Transformer 750 VA 3.6 3.3 1.6 1.3 2.0
Control Transformer 1.0 KVA 4.8 4.4 2.2 1.8 2.6
Convenience Outlet 9.6 8.7 4.4 3.5 N/A
Gas Heat 9.6 8.7 4.4 3.5 5.3
TABLE 32 - ELECTRIC HEAT AMP DRAW
KW*
200V/3Ph/60Hz 240V/3Ph/60Hz 480V/3Ph/60Hz 600V/3Ph/60Hz
AMPS AMPS AMPS AMPS
80 193 193 96 80
108 260 260 130 109
150 181 151
200 241 201
250 301 251
NOTE
Heaters will be sized as follows: 208V heaters rated at 208V, 230V heaters rated at 240V, 460V heaters rated at 480V, 575V heaters rated
at 600V.
