Johnson Controls 100 Series Engineering Guide

JOHNSON CONTROLS
60
FORM100.50-EG12 (918)
TABLE 33 - ELECTRICAL HEAT STAGES
70–80 Tons
80 KW 108 KW 150 KW 200 KW
Available
Voltages
200V/3/60Hz 5 6 NA NA
230V/3/60Hz 5 6 NA NA
460V/3/60Hz 3 3 4 6
575V/3/60Hz 2 3 4 5
90–105 tons
108 KW 150 KW 200 KW 250 KW
Available
Voltages
200V/3/60Hz 6 NA NA NA
230V/3/60Hz 6 NA NA NA
460V/3/60Hz 3 4 6 6
575V/3/60Hz 3 4 5 6
Electrical Data (Cont'd)
