FIRECLASS Fire detection system Install the PNI800 - Network Interface Card
Installation Guide Doc. version 2.0 33
Item Function
J1 See Table 19.
SW1 See Table 20, 21, 22, and
23.
SW2 See Table 24, 25, 26, and
27.
SW3 See Table 28 and 29.
SW4 See Table 30. DIP switch
(Internal N-BUS address)
SW5 Reset button
XT1 FCNET connector
XP1 Slot backplane (Internal
N-BUS) connector
XP2 Auxiliary Zonal LED panel
connector (e.g. for
PNI800 in box)
XP3 Debug Port (RS232) con-
nector
XP4 Auxiliary power supply
connector (e.g. for
PNI800 in box)
XP5 Left fibre optic module
XP6 Right fibre optic module
XP7 Auxiliary JTAG port for
CPU
XP8 Auxiliary JTAG port for
CPLD
Table 18: PNI800 - Jumper, switch and terminal functions
Jumper 1-2 2-3
J1Bypass Normal Mode*
Node Bypassed
[2]
Table 19: PNI800 - J1 jumper setting
* Default.
[2] The MX-Network left and right channels are hardware-con-
nected. Set this only if the PNI800 slot card is non-opera-
tional (due to a fault or not being powered up for example).
SW1 Position Application
1 2
OFF OFF Gateway
ON OFF Bridge
ON ON Hub
OFF ON Reserved
Table 20: PNI800 - Application setting
SW1 Position Network Baud Rate
3 4 5
ON ON ON 9600
OFF ON ON 19200
ON OFF ON 38400
OFF OFF ON 57600
ON ON OFF 76800
OFF ON OFF 115200*
ON OFF OFF Reserved
OFF OFF OFF Reserved
Table 21: PNI800 - Network baud-rate setting
* Default.
SW1 Network Topology
Position 6
ON BUS
OFF RING*
Table 22: PNI800 - Network topology setting
* Default.
SW1 MAIN MCU FW
upgrade mode
Position 8
ON Enabled. Mode is
activated after RESET
OFF Disabled*
Table 23: PNI800- Main MCU FW upgrade mode enable
* Default.
SW2 Host Interface
Position 1
ON RS232
OFF NBUS*
Table 24: PNI800 - Host Interface setting
* Default.
SW2 Emergency Display
Position 2
ON Enabled
OFF Disabled*
Table 25: PNI800 - Emergency display setting
* Default.
