Operation
OPERATION and START-UP INSTRUCTIONS
The Frick
®
RWH Rotary Screw Compressor Unit is an inte
grated system consisting of seven major subsystems:
1. Quantum
™
LX Control Panel
(See publications 090.022O, 090.020M & CS)
2. Compressor
3. Compressor Lubrication System
4. Compressor Oil Separation System
5. Compressor Hydraulic System
6. Compressor Oil Cooling System
7. Compressor EasyStart System
The information in this section of the manual provides the
logical stepbystep instructions to properly start up and
operate the RWH Rotary Screw Compressor Unit.
THE FOLLOWING SUBSECTIONS MUST BE READ AND
UNDERSTOOD BEFORE ATTEMPTING TO START OR OP-
ERATE THE UNIT.
TDSH COMPRESSOR
The Frick
®
RWH rotary screw compressor utilizes mating
asymmetrical prole helical rotors to provide a continuous
ow of refriger ant vapor and is designed for both high
pressure and lowpressure applica tions. The compressor
incorpor ates the following features:
1. Highcapacity roller bearings to carry radial loads at both
the inlet and outlet ends of the compres sor.
2. Heavyduty, fourpoint angularcontact ball bearings to
carry axial loads are mounted at the discharge end of com
pressor.
3. Balance pistons located in the inlet end of the compres sor
to reduce axial loads on the axial load bearings and increase
bearing life.
4. Movable slide valve to provide fully modulating capacity
control from 100% to approximately 10% of full load capacity.
5. Volume ratio control to allow innite ly variable volume
ratio from 2.2 to 5.0 during compres sor operation for all
models. Optional low Vi range is available.
6. A hydraulic unloader cylinder to operate the slide stop
and slide valve.
7. Bearing and casing design for 400 PSI discharge pres
sure for cast ductile iron casing  600 PSI for optional steel
casing. This PSI rating applies only to the compressor and
does not reect the design pressure of the various system
components.
8. All bearing and control oil vented to closed thread in the
compressor instead of suction port to avoid performance
penalties from superheating suction gas.
9. Shaft seal design to maintain operating pressure on seal
well below discharge pressure, for increased seal life.
10. Oil injected into the rotors to maintain good volumetric
and adiabatic efciency even at very high compression ratios.
11. Shaft rotation clockwise facing compressor, suitable for
all types of drives. SEE FOLLOWING WARNING.
WARNING
Compressor rotation is clockwise when facing the
compressor drive shaft. See Figure 20. The compressor
should never be operated in reverse rotation as bearing
damage will result.
Figure 20 - Shaft Rotation Direction
12. Dual compressor casing design for very low airborne noise
transmission.
13. Suction ange is 300 psig ANSI type (except RWH 852 is
CL 400 PLC).
COMPRESSOR LUBRICATION SYSTEM
The lubrication system on an RWH screw com pres sor unit
performs several functions:
1. Provides lubrication to bearings and seal.
2. Provides a cushion between the rotors to minimize noise
and vibrations.
3. Helps keep the compressor cool and prevents overheat ing.
4. Provides an oil supply to hydraulically actuate the slide
valve and slide stop.
5. Provides oil pressure to the balance pistons to help in
crease bearing life.
6. Provides an oil seal between the rotors to prevent rotor
contact or gas bypassing.
The compressor unit is equipped with either a full lube oil
pump or a prelube/control oil pump lubrication system.
Additionally, either system may contain dual oil lters and
liquid injection, watercooled, or thermosyphon oil cooler
for compressor oil cooling.
NOTICE
For alarm descriptions and shutdown or cutout param-
eters, see publication 090.022-O.
CONTROL PUMP OIL SYSTEM
The control oil pump is required to facilitate proper capac
ity control operation of the slide valve. It maintains control
(solenoid)oil pressure 30 to 50 PSI above discharge pressure.
It runs continuously and stops at time of shutdown. The
control oil pump works in conjunction with the discharge
buttery valve control. System pressure differential provides
for lubrication and cooling oil ow.
