RWH ROTARY SCREW COMPRESSOR UNITS

MAINTENANCE

070.620-IOM (DEC 12)

Page 40

COMPRESSOR PORT LOCATIONS - 408 MM

SC-1 SC-3

SC-5

SC-7

SM-1

SC-9

SV-1

SC-9

ST-2

SC-6

ST-1

SC-10

SC-11

VIEW C-C
