Installing the exterior assembly
Use the following steps to install the exterior assembly.
Before you begin: Make sure the bolt is in an unlocked position.
1. Route the cable below the latch.
2. Insert the torque blade into the slotted hole on the latch.
3. Route the cable through the hole in the mounting plate.
IQ Lock-PowerG Installation and User Guide D-30924016
