IQ Lock-PG kit details
Before you install the IQ Lock-PG, ensure the kit contains the following items:
Figure 1: IQ Lock-PG kit
A
B
C
H
I
J
K
L
M
D
F
G
E
Callout Component
A Physical key X 2
B Exterior assembly
C Latch
D Latch screws
E Strike screws
F Strike and optional reinforcement plate
G Mounting plate
H Screws for mounting the interior assembly to the door. Door thickness should
be between 35 mm and 58 mm.
I Interior assembly
J Screws
K Battery cover
L Drive-in collar
M Reset tool
Important: The kit also contains four AA alkaline batteries.
