Note: To install the IQ Lock-PG you need a Philips head screwdriver, a flat head screwdriver,
and a hammer.
Specifications
The following table outlines the IQ Lock-PG technical and mechanical specifications.
Table 1: Specifications
Type Description
Weight 1.6 kg / 3.6 lb
Operating temperature Exterior: -31ºF to 150ºF (-35ºC to 65ºC) Interior:
32ºF to 140ºF (0ºC to 60ºC)
Operating humidity 20% to 95%
Operating voltage 4.6 V to 6.0 V
Battery life Mimimum 12 months, six user code unlock
events, and ten unlocking and locking cycles for
each day
Wireless communication protocol PowerG
Prerequisites
Before you install the IQ Lock-PG, ensure the following requirements are met:
• Measure the door hole to confirm that it is 1 1/2 in. or 2 1/8 in. (38 mm or 54 mm). If the hole
measures 1 1/2 in. (38 mm), remove the fire cup.
Figure 2: Exterior assembly hole dimension and removing the fire cup
• Measure to confirm that the door thickness is between 1 3/8 in. and 2 1/4 in. (35 mm to 58 mm).
• Measure to confirm that the door hole backset is 2 3/8 in. or 2 3/4 in. (60 mm or 70 mm).
• Measure to confirm that the latch hole is 1 in. (25.4 mm) from top to bottom.
IQ Lock-PowerG Installation and User Guide D-3092408
