Installing the interior assembly
Use the following steps to install the interior assembly.
Important: Do not insert the batteries until the lock is completely installed. Do not let the
interior assembly hang while attached to the cable.
1. Remove the battery cover. Connect the cable and ensure it is connected tightly.
If you want to remove the cable, press the top of the white connector and pull the cable out
carefully.
PCB Connector
Cable Connector
2. Rotate the thumb turn to the vertical unlocked position.
Torque Blade
3. Test the lock by rotating the thumb turn to make sure the bolt can extend and retract
smoothly.
IQ Lock-PowerG Installation and User Guide D-30924018
