Johnson Controls J ZB Series User Manual

5808011-JIM-A-0320
Johnson Controls Ducted Systems 11
Table 3: J06-12ZB standard unit weights
Size
(Tons)
Model
Weight (lbs.)
Center of
Gravity
4 point Load Location (lbs.) 6 point Load Location (lbs.)
ShippingOperatingXYABCDABCDEF
J06
(6.5)
ZB 1035 1030 39.6 25.3 245 197 262 327 170 146 126 168 194 226
J07
(7.5)
ZB 1085 1080 38.7 23.7 245 189 281 365 171 142 121 180 212 255
J08
(8.5)
ZB 1089 1084 38.4 24.4 255 193 274 361 178 147 123 175 208 252
J10
(10)
ZB 1090 1085 38.8 24.8 257 199 274 355 179 150 127 175 207 247
J12
(12.5)
ZB 1285 1280 49.6 24.1 231 291 422 335 149 172 202 292 249 215
Table 4: J06-12ZB unit accessory weights
Unit accessory
Weight (lbs.)
Shipping Operating
Economizer 90 85
Power exhaust 40 35
Electric heat
1
49 49
Gas heat
2
110 110
1. The weight given is for the maximum heater size available (54KW).
2. The weight given is for the maximum number of tube heat
exchangers available (8 tubes).
