Table 34: J07ZB charging table - system 1
Air flow
Indoor Db/Wb
Outdoor DB
Suction
pressure
Suction temp.
Discharge
pressure
Liquid temp. Delta T Db
Entering evap
Db
300 Cfm/Ton
80/62
75 141 67 284 87 -25 7.3
85 140 64 329 96 -26 8.2
95 138 61 375 106 -26 9.2
300 Cfm/Ton
79.89/67.03
75 141 65 283 88 -25 7.3
85 144 64 331 97 -24 8.3
95 146 64 379 106 -23 9.2
300 Cfm/Ton
80/72
75 141 63 283 89 -25 7.3
85 147 65 333 98 -22 8.3
95 154 66 383 106 -19 9.3
300 Cfm/Ton
75/62
75 135 62 282 86 -22 7.2
85 135 60 329 95 -22 8.2
95 135 59 376 104 -22 9.2
400 Cfm/Ton
80/62
75 145 69 286 86 -23 7.4
85 147 67 332 96 -23 8.3
95 148 65 379 106 -22 9.2
400 Cfm/Ton 79.88/
67.035
75 147 68 286 87 -22 7.4
85 150 68 333 97 -21 8.3
95 153 67 380 107 -20 9.2
400 Cfm/Ton
80/72
75 149 68 286 88 -21 7.4
85 153 68 334 98 -20 8.3
95 158 68 382 108 -18 9.2
400 Cfm/Ton
75/62
75 140 65 284 86 -20 7.3
85 141 64 331 95 -19 8.3
95 143 62 379 105 -19 9.2
Table 35: J07ZB charging table - system 2
Air flow
Indoor Db/Wb
Outdoor DB
Suction
pressure
Suction temp.
Discharge
pressure
Liquid temp. Delta T Db
Entering evap
Db
300 Cfm/Ton
80/62
75 140 67 279 87 -25 6.8
85 138 64 323 96 -26 7.6
95 137 61 367 106 -26 8.5
300 Cfm/Ton
79.89/67.03
75 139 65 279 88 -25 6.8
85 142 64 325 97 -24 7.7
95 146 64 372 106 -23 8.5
300 Cfm/Ton
80/72
75 138 63 278 89 -25 6.8
85 146 65 327 98 -22 7.7
95 155 66 376 106 -19 8.5
300 Cfm/Ton
75/62
75 133 62 277 87 -22 6.7
85 134 60 322 95 -22 7.6
95 134 59 368 104 -22 8.5
400 Cfm/Ton
80/62
75 145 70 281 86 -23 6.8
85 146 69 326 96 -23 7.7
95 147 67 372 106 -22 8.5
400 Cfm/Ton
79.88/67.035
75 146 69 281 87 -22 6.9
85 149 68 327 97 -21 7.7
95 152 67 374 107 -20 8.5
400 Cfm/Ton
80/72
75 147 67 281 88 -21 6.9
85 152 67 329 98 -20 7.7
95 157 66 376 108 -18 8.5
400 Cfm/Ton
75/62
75 139 65 279 86 -20 6.8
85 141 64 325 95 -19 7.7
95 143 63 371 105 -19 8.5
