5808011-JIM-A-0320
Johnson Controls Ducted Systems 77
Table 36: J08ZB charging table - system 1
Air flow
Indoor Db/Wb
Outdoor DB
Suction
pressure
Suction temp.
Discharge
pressure
Liquid temp. Delta T Db
Entering evap
Db
300 Cfm/Ton
80/62
75 145 62 269 269 -25 7.4
85 144 60 314 314 -26 8.2
95 143 58 359 359 -26 9.1
300 Cfm/Ton
79.82/66.95
75 144 61 268 268 -25 7.4
85 146 61 315 315 -24 8.3
95 148 61 363 363 -24 9.2
300 Cfm/Ton
80/72
75 142 60 266 266 -25 7.4
85 148 62 317 317 -23 8.4
95 154 63 367 367 -21 9.3
300 Cfm/Ton
75/62
75 139 59 267 267 -23 7.4
85 139 57 314 314 -23 8.3
95 139 56 361 361 -22 9.1
400 Cfm/Ton
80/62
75 151 66 270 270 -23 7.4
85 151 64 316 316 -22 8.3
95 152 62 362 362 -22 9.1
400 Cfm/Ton
80.005/66.92
75 150 65 269 269 -23 7.5
85 152 64 316 316 -22 8.3
95 154 63 363 363 -21 9.2
400 Cfm/Ton
80/72
75 149 63 269 269 -22 7.5
85 153 63 316 316 -21 8.4
95 156 64 364 364 -20 9.3
400 Cfm/Ton
75/62
75 144 62 268 268 -20 7.4
85 145 60 315 315 -20 8.3
95 146 59 363 363 -19 9.2
Table 37: J08ZB charging table - system 2
Air flow
Indoor Db/Wb
Outdoor DB
Suction
pressure
Suction temp.
Discharge
pressure
Liquid temp. Delta T Db
Entering evap
Db
300 Cfm/Ton
80/62
75 143 467 277 83 -25 7.1
85 143 467 321 91 -26 7.9
95 144 468 365 99 -26 8.7
300 Cfm/Ton
79.82/66.95
75 141 466 274 82 -25 7.0
85 144 465 320 90 -24 7.9
95 147 465 367 98 -24 8.8
300 Cfm/Ton
80/72
75 139 464 272 82 -25 6.9
85 144 463 320 90 -23 7.9
95 150 463 368 97 -21 8.9
300 Cfm/Ton
75/62
75 135 465 276 81 -23 7.1
85 137 466 321 89 -23 7.9
95 139 467 366 98 -22 8.8
400 Cfm/Ton
80/62
75 149 466 278 83 -23 7.1
85 151 466 322 91 -22 7.9
95 153 467 367 100 -22 8.8
400 Cfm/Ton
80.005/66.92
75 148 464 276 82 -23 7.1
85 151 465 322 90 -22 7.9
95 154 466 367 98 -21 8.8
400 Cfm/Ton
80/72
75 147 463 275 82 -22 7.0
85 151 464 321 89 -21 7.9
95 154 465 368 97 -20 8.8
400 Cfm/Ton
75/62
75 142 465 276 81 -20 7.1
85 145 465 321 90 -20 7.9
95 147 466 366 98 -19 8.8
