Table 38: J10ZB charging table - system 1
Air flow
Indoor Db/Wb
Outdoor DB
Suction
pressure
Suction temp.
Discharge
pressure
Liquid temp. Delta T Db
Entering evap
Db
300 Cfm/Ton
80/62
75 138 64 279 84 -25 9.3
85 137 62 325 93 -26 10.4
95 136 60 371 102 -26 11.5
300 Cfm/Ton
79.97/67.09
75 137 63 279 83 -25 9.4
85 141 63 326 93 -24 10.5
95 144 63 373 102 -24 11.5
300 Cfm/Ton
80/72
75 137 63 279 83 -25 9.4
85 144 65 327 93 -23 10.5
95 151 66 375 103 -21 11.5
300 Cfm/Ton
75/62
75 132 60 277 82 -23 9.3
85 133 59 324 91 -23 10.4
95 134 58 371 101 -23 11.6
400 Cfm/Ton
80/62
75 143 67 281 84 -23 9.4
85 144 65 328 93 -22 10.5
95 145 64 374 103 -22 11.6
400 Cfm/Ton
80/67.005
75 143 66 282 83 -22 9.5
85 146 65 328 93 -22 10.6
95 149 65 375 102 -21 11.6
400 Cfm/Ton
80/72
75 142 65 282 82 -22 9.6
85 147 66 329 92 -21 10.6
95 152 66 376 102 -19 11.6
400 Cfm/Ton
75/62
75 137 63 280 82 -20 9.4
85 139 62 327 91 -20 10.5
95 141 61 374 101 -19 11.6
Table 39: J10ZB charging table - system 2
Air flow
Indoor Db/Wb
Outdoor DB
Suction
pressure
Suction temp.
Discharge
pressure
Liquid temp. Delta T Db
Entering evap
Db
300 Cfm/Ton
80/62
75 142 59 285 86 -25 9.3
85 142 57 334 94 -26 10.4
95 141 56 382 102 -26 11.5
300 Cfm/Ton
79.97/67.09
75 142 58 286 86 -25 9.3
85 145 58 336 94 -24 10.5
95 148 58 385 102 -24 11.7
300 Cfm/Ton
80/72
75 141 58 287 86 -25 9.3
85 148 59 337 94 -23 10.6
95 155 60 388 103 -21 11.9
300 Cfm/Ton
75/62
75 136 56 283 85 -23 9.2
85 137 55 333 93 -23 10.4
95 138 54 382 101 -23 11.5
400 Cfm/Ton
80/62
75 148 62 288 87 -23 9.3
85 149 61 337 95 -22 10.5
95 151 59 386 104 -22 11.6
400 Cfm/Ton
80/67.005
75 148 61 289 87 -22 9.4
85 151 61 338 95 -22 10.5
95 153 61 387 102 -21 11.7
400 Cfm/Ton
80/72
75 148 61 290 87 -22 9.4
85 152 61 339 94 -21 10.5
95 156 62 389 101 -19 11.7
400 Cfm/Ton
75/62
75 141 58 287 85 -20 9.3
85 144 58 336 94 -20 10.4
95 146 57 385 102 -19 11.6
