Johnson Controls J ZB Series User Manual

5808011-JIM-A-0320
Johnson Controls Ducted Systems 33
J10
(10)
208-3-60 16.2 110 25 3.03 9.6 5.5 20
None - - - 67.9 73.4 80 80
E18 13.5 2 37.5 71.4 78.3 80 80
E24 18 2 50 87 93.9 90 100
E36 25.5 2 70.8 113 119.9 125 125
E54 40.6 2 112.7 165.4 172.3 175 175
230-3-60 16.2 110 25 3.03 9.6 5.5 20
None - - - 67.9 73.4 80 80
E18 18 2 43.3 78.6 85.5 80 90
E24 24 2 57.7 96.6 103.5 100 110
E36 34 2 81.8 126.8 133.6 150 150
E54 54 2 129.9 154.4 161.3 175 175
460-3-60 7.6 52 12 1.6 4.7 2.2 20
None - - - 32.7 34.9 40 40
E18 18 2 21.7 39.3 42 40 45
E24 24 2 28.9 48.3 51 50 60
E36 34 2 40.9 63.3 66 70 70
E54 54 2 65 77.1 79.9 90 90
575-3-60 5.1 43.8 8 1.35 3.2 1.8 20
None - - - 21.4 23.2 25 25
E18 18 2 17.3 30.6 32.9 35 35
E24 24 2 23.1 37.9 40.1 40 45
E36 34 2 32.7 49.9 52.1 50 60
E54 54 2 52 61 63.3 70 70
J12
(12.5)
208-3-60 18.6 149 29 2.1 14 5.5 20
None - - - 79 84.5 100 100
E18 13.5 2 37.5 79 84.5 100 100
E24 18 2 50 92.5 99.4 100 100
E36 25.5 2 70.8 118.5 125.4 125 150
E54 40.6 2 112.7 170.9 177.8 175 200
230-3-60 18.6 149 29 2.1 14 5.5 20
None - - - 79 84.5 100 100
E18 18 2 43.3 84.1 91 100 100
E24 24 2 57.7 102.1 109 110 110
E36 34 2 81.8 132.3 139.1 150 150
E54 54 2 129.9 159.9 166.8 175 175
460-3-60 9 60.9 14 1.26 6.6 2.2 20
None - - - 38.9 41.1 45 50
E18 18 2 21.7 41.6 44.4 45 50
E24 24 2 28.9 50.6 53.4 60 60
E36 34 2 40.9 65.6 68.4 70 70
E54 54 2 65 79.5 82.3 90 90
575-3-60 7.1 56 11 0.66 5.2 1.8 20
None - - - 28.5 30.3 35 35
E18 18 2 17.3 33.1 35.4 35 40
E24 24 2 23.1 40.4 42.6 45 45
E36 34 2 32.7 52.4 54.6 60 60
E54 54 2 52 63.5 65.8 70 70
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
Electric heat multipliers
Voltage
kW capacity multipliers
1
1. Electric heaters are rated at nominal voltage. Use this table to determine the electric heat
capacity for heaters applied at lower voltages.
Nominal Applied
240
208 0.75
230 0.92
480 460 0.92
600 575 0.92
J06-12ZB High Static Indoor Blower - With Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max fuse
2
/
breaker
3
size
(amps)
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
