Operating Instructions—IFC-200 Operating Instructions 19
Where:
OFF is the zone status (could be ON)
FLR 5 MAIN BUILDING is the custom programmed label for this zone.
Z20 is the zone number
Note: To read the status of a zone directly, press “*”, then “#”, then the
zone two digit number, then ENTER.
The following typical format is used to display software Zone 90
(Presignal Delay Control):
OFF SOFTWARE ZONE
PRESIGNAL DELAY
DELAY=180
PAS=YES Z90
Where:
DELAY=180 indicates the programmed presignal delay in seconds.
PAS=YES indicates that Positive Alarm Sequence operation has been
selected in the program. If PAS has not been selected, the line reads
PAS=NO.
Z90 is the selected zone number.
The following typical display is used for Zones 91, 92, 93, or 94
(Releasing Control Zones):
OFF SOFTWARE ZONE
RELEASE CONTROL
DELAY=30 ABORT=ULI
CROSS=Y SOAK=10 Z91
Where:
DELAY=30 indicates programmed delay time, in seconds.
ABORT=ULI indicates the abort function, if an abort switch is mapped to
this zone (ULI, IRI, NYC, or AHJ).
CROSS=Y indicates that cross zoning is used (two or more detectors must
be programmed to this zone to activate the zone in alarm).
SOAK indicates the soak timer (automatic shut off) value in minutes.
(00 = no soak timer).
To Next Page
