Johnson Controls R-410A - Dual Stage Wiring Interconnection

349218-JIM-F-0512
16 Johnson Controls Unitary Products
Table 8: Electrical Data
J15 thru 25 ZJ - Standard Drive Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
J15
(15)
208-3-60 14.7 115 23.0 2.1 15.4 0.0
None - - - 86.5 100
E18 13.5 1 37.5 86.5 100
E36 27.0 2 74.9 112.9 125
E54 40.6 2 112.7 160.1 175
E72 54.1 2 150.2 169.4 200
230-3-60 14.7 115 23.0 2.1 14.4 0.0
None - - - 85.3 90
E18 18.0 1 43.3 85.3 90
E36 36.0 2 86.6 126.3 150
E54 54.0 2 129.9 147.9 175
E72 72.0 2 173.2 191.2 225
460-3-60 7.7 50 12.0 1.1 7.2 0.0
None - - - 44.3 50
E18 18.0 1 21.7 44.3 50
E36 36.0 2 43.3 63.1 70
E54 54.0 2 65.0 74.0 90
E72 72.0 2 86.6 95.6 110
575-3-60 6.4 40 10.0 0.9 5.9 0.0
None - - - 36.7 40
E18 18.0 1 17.3 36.7 40
E36 36.0 2 34.6 50.7 60
E54 54.0 2 52.0 59.3 70
E72 72.0 2 69.3 76.7 90
J18
(17.5)
208-3-60 16.7 120 26.0 2.1 15.4 0.0
None - - - 94.8 110
E18 13.5 1 37.5 94.8 110
E36 27.0 2 74.9 112.9 125
E54 40.6 2 112.7 160.1 175
E72 54.1 2 150.2 169.4 200
230-3-60 16.7 120 26.0 2.1 14.4 0.0
None - - - 93.8 110
E18 18.0 1 43.3 93.8 110
E36 36.0 2 86.6 126.3 150
E54 54.0 2 129.9 147.9 175
E72 72.0 2 173.2 191.2 225
460-3-60 8.7 60 15.5 1.1 7.2 0.0
None - - - 48.6 50
E18 18.0 1 21.7 48.6 50
E36 36.0 2 43.3 63.1 70
E54 54.0 2 65.0 74.0 90
E72 72.0 2 86.6 95.6 110
575-3-60 6.7 42 10.5 0.9 5.9 0.0
None - - - 38.0 40
E18 18.0 1 17.3 38.0 40
E36 36.0 2 34.6 50.7 60
E54 54.0 2 52.0 59.3 70
E72 72.0 2 69.3 76.7 90
J20
(20)
208-3-60 17.9 120 28.0 3.7 15.4 0.0
None - - - 106.3 110
E18 13.5 1 37.5 106.3 110
E36 27.0 2 74.9 112.9 125
E54 40.6 2 112.7 160.1 175
E72 54.1 2 150.2 169.4 200
230-3-60 17.9 120 28.0 3.7 14.4 0.0
None - - - 105.3 110
E18 18.0 1 43.3 105.3 110
E36 36.0 2 86.6 126.3 150
E54 54.0 2 129.9 147.9 175
E72 72.0 2 173.2 191.2 225
460-3-60 9.6 70 15.0 1.9 7.2 0.0
None - - - 55.6 60
E18 18.0 1 21.7 55.6 60
E36 36.0 2 43.3 63.1 70
E54 54.0 2 65.0 74.0 90
E72 72.0 2 86.6 95.6 110
575-3-60 7.4 53 11.5 1.5 5.9 0.0
None - - - 43.4 50
E18 18.0 1 17.3 43.4 50
E36 36.0 2 34.6 50.7 60
E54 54.0 2 52.0 59.3 70
E72 72.0 2 69.3 76.7 90
