System 450™ Series Control Module with Ethernet Communications Installation Instructions
12
P 500 PSI (Pressure/psi) 0 to 500 90 to 500 1 5 P499RAP-105C
P499RAP-105K
P499RCP-105C
P499RCP-105K
P598RAPSN105C
P598RAPSN105K
P598RCPSN105C
P598RCPSN105K
P 750 PSI (Pressure/psi) 0 to 750 150 to 750 2 6 P499RAP-107C
P499RAP-107K
P499RCP-107C
P499RCP-107K
P598RAPSN107C
P598RAPSN107K
P598RCPSN107C
P598RCPSN107K
HIF F (Temperature/degrees) -50 to 360
-40 to 350
4
1 1 TE-631x, TE-6000-x,
TE-68NT-0N00S
HIC C (Temperature/degrees) -45.5 to 182
-40 to 176
4
0.5 0.5 TE-631x-x
TE-6000-x
TE-68NT-0N00S
bin
Open or Closed
5
N/A N/A N/A N/A N/A
1. Because of the way that the System 450 Differential Sensor (Sn-d) is set up and calculated with two identical sensors
(Sn-1 and Sn-2), the Range of Usable Values is twice as large as a single sensor. See Table 7 on page 16 for the Range of
Usable Values when an output references Sn-d.
2. Refer to the System 450 Series Modular Controls Product Bulletin (LIT-12011458), System 450 Series Modular Controls
Catalog Page (LIT-1900549), or the System 450 Series Controls Systems with Communications Technical Bulletin (LIT-
12011826) for additional ordering information for System 450 compatible sensors and transducers.
3. See Setting Up Outputs That Reference a P 110 Sensor
on page 14 for information on setting up System 450 outputs that
reference the P 110 Sensor Type.
4. Many of the temperature sensors that can be set up as HI°F or HI°C Sensor Types are not designed for use across the
entire range of usable values for HI°F and HI°C Sensor Types. Refer to the Technical Specifications for the sensor you
intend to use to determine the ambient temperature range that the sensor is specified to operate in. The TE-6000-6 Nickel
Sensor is the only sensor designed for use over the entire temperature range.
5. Selecting the bin Sensor Type for a sensor (Sn-1, Sn-2, or Sn-3) sets up the input to control relay outputs (only) based on
the state of the binary input contacts (open or closed) connected to the sensor input (Sn1, Sn2, or Sn3). See Binary Input
Control for Relay Outputs on page 15 for more information.
Table 4: System 450 Sensor Types, Setup Values, and Sensor/Transducer Product Codes (Part 2 of 2)
Sensor
Type
Unit of Measurement
Value
(Condition/Units)
Effective
Sensing
Range
Range of
Usable
Values
1
Resolution
Increment
Value
Minimum
Proportional
or Control
Band
Sensor Product Type
Number
2
