TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 13
Fan Status
2, 5
MSV 28 1 = Off
2 = Low
3=Med
4 = High
BI1 Status
5
BI 29 0 = Deactivated
1 = Activated
BI2 Status
5, 6
BI 30 0 = Deactivated
1 = Activated
UI3 Status
5, 6
BI 31 0 = Deactivated
1 = Activated
Local Motion
5
BI 32 0 = No Motion
1=Motion
Effective Occupancy
5
MSV 33 1 = Occupied
2 = Unoccupied
3 = Temporary Occupied
4 = Stand-by
Window Alarm
5
BI 35 0 = Off
1=On
Filter Alarm
5
BI 36 0 = Off
1=On
Service Alarm
5
BI 37 0 = Off
1=On
Occupied Heat Setpoint
3
AV 39 40.0°F/4.5°C to
90.0°F/32.0°C
Occupied Cool Setpoint
3, 7
AV 40 54.0°F/12.0°C to
100.0°F/37.5°C
Stand-by Heat Setpoint
3, 7
AV 41 40.0°F/4.5°C to
90.0°F/32.0°C
Stand-by Cool Setpoint
3, 7
AV 42 54.0°F/12.0°C to
100.0°F/37.5°C
Unoccupied Heat Setpoint
3, 7
AV 43 40.0°F/4.5°C to
90.0°F/32.0°C
Unoccupied Cool Setpoint
3, 7
AV 44 54.0°F/12.0°C to
100.0°F/37.5°C
Table 3: TEC26x6(H)-4 and TEC26x6H-4+PIR Series MS/TP Bus Objects
(Part 3 of 7)
Point Name Thermostat Point
(Type/Address)
Range
